Placa de Baza GIGABYTE Z790 S DDR4 LGA1700

Placa de Baza GIGABYTE Z790 S DDR4 LGA1700, 4x DDR4, 1x DP 1x HDMI, 3x PCIE x16, 3x M.2, 4x SATA 6GB/s, ATX

Battery weight

3 g

Lithium weight per battery

0.07 g

Number of battery cells

1

Battery technology

Lithium-Manganese Dioxide (LiMnO2)

Battery type

CR2032

BIOS type

UEFI AMI

BIOS memory size

256 Mbit

Clear CMOS jumper

Yes

ACPI version

5.0

Desktop Management Interface (DMI) version

2.7

System Management BIOS (SMBIOS) version

2.7

Product colour

Brown

PCI Express x16 slots

3

PCI Express x1 slots

2

Number of M.2 (M) slots

3

Motherboard chipset

Intel Z790 Express

Motherboard form factor

ATX

Motherboard chipset family

Intel

PC health monitoring

Fan, Temperature, Voltage, Water cooling

Audio output channels

7.1 channels

Component for

PC

Windows operating systems supported

Windows 10 x64, Windows 11 x64

DirectX version

12.0

HDCP

Yes

Maximum resolution

4096 x 2304 pixels

Total number of SATA connectors

4

Thunderbolt headers

2

12V power connector

Yes

S/PDIF out connector

Yes

Serial port headers

1

USB 2.0 connectors

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

Number of SATA III connectors

4

Front panel audio connector

Yes

ATX Power connector (24-pin)

Yes

CPU fan connector

Yes

EPS power connector (8-pin)

Yes

USB 3.2 Gen 2 (3.1 Gen 2) connectors

1

Front panel connector

Yes

TPM connector

Yes

RGB LED pin header

Yes

Products per shipping (inner) case

1 pc(s)

Country of origin

China

Memory channels

Dual-channel

Maximum internal memory

128 GB

Supported memory types

DDR4-SDRAM

ECC сompatibility

ECC & Non-ECC

Number of memory slots

4

Memory slots type

DIMM

Unbuffered memory

Yes

Supported memory module capacities

1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB

Supported memory clock speed (max)

5333 MHz

Ethernet interface type

2.5 Gigabit Ethernet

Ethernet LAN

Yes

Wi-Fi

No

Batteries included

Yes

Bundled software

Norton Internet Security

Cables included

SATA

Package weight

1.79 kg

Package width

335 mm

Package depth

270 mm

Package height

80 mm

Warranty period

3 year(s)

HDMI version

2.0

HDMI ports quantity

1

DVI-D ports quantity

0

Processor manufacturer

Intel

Processor socket

LGA 1700

Supported processor sockets

LGA 1700

Maximum internal memory supported by processor

128 GB

Headphone outputs

6

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

Ethernet LAN (RJ-45) ports

1

USB connector type

USB Type-A, USB Type-C

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

1

Microphone in

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

0

VGA (D-Sub) ports quantity

0

USB 2.0 ports quantity

5

PS/2 ports quantity

1

Supported storage drive interfaces

M.2, SATA III

Number of HDDs supported

4

Number of storage drives supported

7

RAID levels

0, 1, 5, 10

Supported storage drive types

HDD & SSD

RAID support

Yes

Width

305 mm

Depth

244 mm

Height

35 mm

Onboard-CPU

No

PCI

0

Serial-or-Paralel

No/No
