Placa de Baza MSI PRO B860M-A WIFI LGA 1851, 4x DDR5, 1x HDMI 1x DP 1x Type-C DP, 4x PCIE x16, 3x M.2, 4x SATA 6GB/s, mATX
BIOS type
UEFI AMI
BIOS memory size
256 Mbit
ACPI version
6.5
System Management BIOS (SMBIOS) version
3.7
Product colour
Black
PCI Express x16 (Gen 5.x) slots
1
Number of M.2 (M) slots
3
1st M.2 highest PCI Express generation
5.0
2nd M.2 highest PCI Express generation
4.0
3rd M.2 highest PCI Express generation
4.0
PCI Express x16 (Gen 4.x) slots
3
1st M.2 largest key size
2280
2nd M.2 largest key size
2280
3rd M.2 largest key size
2280
Motherboard chipset
Intel B860
Windows operating systems supported
Windows 11 x64
Motherboard form factor
micro ATX
Motherboard chipset family
AMD
Audio Chip
Realtek ALC897
Audio output channels
7.1 channels
Component for
PC
On-board graphics card
No
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
RGB LED pin header
Yes
Number of SATA III connectors
4
Number of SATA II connectors
0
Number of SATA connectors
0
CPU fan connector
Yes
Total number of SATA connectors
4
USB 2.0 connectors
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
4
Number of water pump connectors
1
Number of CPU fan connectors
1
Number of RGB LED pin headers
3
Supported memory clock speeds
4800,6400,8800 MHz
Supported memory clock speed (max)
8800 MHz
ECC сompatibility
Non-ECC
Supported memory types
DDR5-SDRAM
Maximum internal memory
256 GB
Number of memory slots
4
Memory slots type
DIMM
Memory channels
Dual-channel
BLUETOOTH
Yes
Ethernet LAN
Yes
Wi-Fi
Yes
Bluetooth version
5.4
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Ethernet interface type
5 Gigabit Ethernet
mSATA ports quantity
0
HDMI version
2.1
DVI-D ports quantity
0
HDMI ports quantity
1
Processor manufacturer
Intel
Processor socket
LGA 1851 (Socket V1)
Supported processor sockets
LGA 1851
Compatible processor series
Intel Core Ultra (Series 2)
Maximum internal memory supported by processor
256 GB
Ethernet LAN (RJ-45) ports
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
VGA (D-Sub) ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 2.0 ports quantity
2
Supported storage drive types
HDD & SSD
RAID support
Yes
Number of HDDs supported
4
Number of storage drives supported
7
RAID levels
0, 1, 5, 10
Supported storage drive interfaces
M.2, Micro SATA III
Depth
243.8 mm
Width
243.8 mm
Onboard-CPU
No
PCI
0
Serial-or-Paralel
No/No
