Procesor INTEL CORE ULTRA5 245KF pana la 5.2GHz LGA1851, 14 cores 20 threads, Intel Smart Cache 24MB, L2 Cache 26MB, TRAY

Procesor INTEL CORE ULTRA5 245KF pana la 5.2GHz LGA1851, 14 cores 20 threads, Intel Smart Cache 24MB, L2 Cache 26MB, TRAY

Embedded options available

No

Execute Disable Bit

Yes

Idle States

Yes

Thermal Monitoring Technologies

Yes

Supported instruction sets

AVX 2.0, SSE4.1, SSE4.2

Use conditions

PC/Client/Tablet

Scalability

1S

Direct Media Interface (DMI) Revision

4.0

Export Control Classification Number (ECCN)

5A992C

Commodity Classification Automated Tracking System (CCATS)

740.17B1

Thermal solution specification

PCG 2020A

Market segment

Desktop

PCI Express slots version

4.0, 5.0

Maximum number of PCI Express lanes

24

On-board graphics card

No

On-board graphics card model

Not available

Discrete graphics card

No

Discrete graphics card model

Not available

Harmonized System (HS) code

8542310050

Memory clock speeds supported by processor

6400 MHz

Memory types supported by processor

DDR5-SDRAM

Memory channels

Dual-channel

Maximum internal memory supported by processor

192 GB

Neural processor unit (NPU)

Intel AI Boost

Sparsity support

Yes

Windows Studio effects support

Yes

Total processor performance up to

22 TOPs

AI software frameworks supported by NPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

NPU performance up to

13 TOPs

Maximum operating temperature

105 °C

L2 cache

26624 KB

Maximum internal memory

192 GB

Box

Yes

Cooler included

No

Processor base power

125 W

Processor family

Intel Core Ultra 5

Performance-core boost frequency

5.2 GHz

Processor operating modes

64-bit

Processor cores

14

Processor boost frequency

5.2 GHz

Processor manufacturer

Intel

Efficient cores

8

Processor cache type

Smart Cache

Performance cores

6

Processor cache

24 MB

Processor model

245KF

Processor ARK ID

241066

Stepping

B0

Maximum number of DMI lanes

8

Processor socket

FCLGA1851

Processor generation

Intel Core Ultra (Series 2)

Performance-core base frequency

4.2 GHz

Efficient-core boost frequency

4.6 GHz

Efficient-core base frequency

3.6 GHz

Maximum turbo power

159 W

AI software frameworks supported by CPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

Processor codename

Arrow Lake

Intel® Speed Shift Technology

Yes

Intel® Control-flow Enforcement Technology (CET)

Yes

Intel® Thread Director

Yes

Intel® Boot Guard

Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU

Yes

Intel® Volume Management Device (VMD)

Yes

Mode-based Execute Control (MBE)

Yes

Intel® Standard Manageability (ISM)

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel Trusted Execution Technology

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Virtualization Technology (VT-x)

Yes

Enhanced Intel SpeedStep Technology

Yes

Intel® AES New Instructions (Intel® AES-NI)

Yes

Intel® Secure Key

Yes

Intel® OS Guard

Yes

Intel 64

Yes

Intel® Turbo Boost Technology

2.0

Intel® Thunderbolt 4

Yes

Status

Launched

Launch date

Q4'24

Memory speed (max)

6400 MHz
