Sursa CORSAIR SF850 8500W 80 PLUS Platinum SFX

Sursa CORSAIR SF850 8500W 80 PLUS Platinum SFX, ATX 3.1, Fully Modular, Active PFC

Number of fans

1 fan(s)

Fan location

Top

Fan diameter

14 cm

Cables included

AC

Purpose

PC

Mean time between failures (MTBF)

100000 h

Power supply unit (PSU) form factor

ATX

Silent mode

Yes

ATX version

3.1

80 PLUS certification

80 PLUS Gold

Bearing technology

FDB

Number of SATA power connectors

12

PCI Express power cable length

75 cm

PCI Express power connectors (6+2 pin)

8

Number of PATA power connectors

4

SATA power cable length

115,455,800 mm

Motherboard power cable length

61 cm

Peripheral (Molex) power cable length

750 mm

Cabling type

Fully-Modular

Motherboard power connector

24-pin ATX

EPS power connector (8-pin)

Yes

Peripheral (Molex) power connectors (4-pin)

1

Input current

10 A

AC input voltage

100 - 240 V

Combined power (+3.3V)

150 W

Combined power (+5V)

150 W

AC input frequency

47 - 63 Hz

Power protection features

Over power, Over voltage, Overheating, Short circuit, Under voltage

Max output current (+3.3V)

20 A

Max output current (+5V)

20 A

Maximum input current (@110V)

10 A

Maximum input current (@220V)

5 A

Total power

850 W

Combined power (+12V)

849.6 W

Max output current (+12V)

70.8 A

Weight

3.3 kg
