Sursa NJOY TITAN+ 750W 80+ BRONZE

Sursa NJOY TITAN+ 750W 80+ BRONZE, ATX, Active PFC, Protectie OVP / OCP / SCP / OPP, negru

Number of fans

1 fan(s)

On/off switch

Yes

Product colour

Black, Orange

Fan diameter

12 cm

Products per master (outer) case

10 pc(s)

Master (outer) case height

265 mm

Master (outer) case width

375 mm

Master (outer) case length

525 mm

Master (outer) case net weight

17.6 kg

Master (outer) case gross weight

18.4 kg

Parallel processing technology support

CrossFireX, SLI

Power plug type

Type F

Cables included

AC

Package width

240 mm

Package height

180 mm

Package depth

100 mm

Package weight

1.76 kg

Purpose

PC

80 PLUS certification

80 PLUS Bronze

Supported motherboard form factors

ATX

Bearing technology

Hydraulic

Power supply unit (PSU) form factor

ATX

ATX version

2.53

Continuous output rated temperature

105 °C

SATA power cable length

400,530,790,920,660 mm

Peripheral (Molex) power cable length

600 mm

PCI Express power cable length

65 cm

Number of EPS connectors

1

Peripheral (Molex) power connectors (4-pin)

4

Motherboard power connector

20+4 pin ATX

Number of SATA power connectors

6

PCI Express power connectors (6+2 pin)

4

Motherboard power cable length

50 cm

Number of +12V rail(s)

1

Combined power (+3.3V)

90 W

Combined power (+5V)

90 W

Efficiency

88%

Total power

750 W

AC input frequency

47 - 63 Hz

Power Factor Correction (PFC) type

Active

Combined power (+12V)

744 W

Max output current (+12V)

62 A

AC input voltage

230 V

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

12.5 W

Max output current (+3.3V)

15 A

Max output current (+5V)

15 A

Max output current (-12V)

0.3 A

Max output current (+5Vsb)

2.5 A

Power protection features

Over current, Over power, Over voltage, Short circuit

Height

86 mm

Depth

140 mm

Width

150 mm

Weight

1.58 kg
